Just right for your living room, media room, or bespoke home theater, the DRX-3.4 has the power to drive Dolby Atmos® and DTS: X® through 9 channels of onboard amplification. 8K HDR video passthrough provides the bandwidth needed for cutting-edge visuals and gaming. DIRAC Live room correction ensures your immersive surround experience is delivered with the highest fidelity. 9.2 channel pre-outs make the DRX-3.4 perfect for updating an existing separates system to HDMI 2.1, DIRAC Live, and Object-Based Surround.
Warranty:
1-year manufacturer's warranty
Features:
- Integra DRX 3.4 delivers stunning visuals with its 8K upscaling capability, enhancing lower resolution content to near-8K quality
- Experience enveloping, multidimensional sound with Dolby Atmos support, providing a truly cinematic audio experience.
- Enjoy crystal-clear and detailed audio playback with support for high-resolution audio formats like FLAC and DSD.
- Easily power and control speakers in another room with the dedicated Zone 2 outputs, expanding your audio setup.
- Automatically calibrate your audio system to your room's acoustics for optimal sound performance and balance.
Video Review:
DIRAC LIVE Room Correction
Considered by industry leaders in music and movie production to be the state-of-the-art digital room correction solution, Dirac Live offers professional-grade, studio-quality calibrated sound with simple, easy-to-navigate tools. The result is a home theater experience that reveals your movies, music, and games in ways you’ve never heard before. Unlock the full potential of your loudspeakers in any listening space with Dirac Live.
imax-enhanced
Hear the sound filmmakers intended. This IMAX Enhanced A/V receiver features DTS:X sound technology optimized for the IMAX® signature experience, reproducing the full dynamic range of IMAX theatrical sound-mixes available with digitally re-mastered IMAX Enhanced content. A pre-set IMAX Mode reproduces audio at the highest levels and delivers an unmatched IMAX sound experience. Requires a free firmware update.
Dolby Atmos Height Virtualizer
When playing any Dolby® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without the need for additional surround or height speakers.
dolby-atmos-dtsX-logo
Supports Dolby Atmos and DTS:X for an immersive three-dimensional sound-space through 7.2.2 or 5.2.4 channels. Individual sounds aren’t tied to channels and move naturally around your audience.
Perfect for Custom Installation
Integra products are designed and engineered to meet the demands of leading custom installers. CI Centric features such as Web Setup, Onboard HDMI Diagnostics, and compatibility with Remote Monitoring systems like OVRC Pro and Domotz make Integra AVRs the choice of the modern integrator. Optional rack mount kits provide a clean, finished look when installed in racks and cabinets, while a unique bright white back panel facilitates connections in hard-to-reach areas.
Technical Specifications:
| Sales Package |
Integra DRX 3.4 8K with Dolby Atmos AV Receiver, User documentation
|
| Brand | Integra |
| Model | DRX 3.4 |
| Color | black |
| Power Output Front L/R |
225 W/Ch at 6 Ohms, 1 kHz, 10%, 1 Channel Driven, 100 W/Ch at 8 Ohms, 20 Hz–20 kHz, 0.08%, 2 Channels Driven, FTC
|
| Dynamic Power |
250 W (3 Ohms, Front) 220 W (4 Ohms, Front) 130 W (8 Ohms, Front)
|
| Input Sensitivity and Impedance |
200 mV rms/47 k-Ohms (Line/Unbalance) 3.5 mV rms/47
|
| k-Ohms (Phono MM) THD N (Total Harmonic Distortion Noise) | 0.08% (20 Hz–20 kHz, Half Power) |
| Rated RCA Output Level and Impedance |
1 V rms/470 Ohms (Subwoofer Pre-out) 200 mV rms/470 Ohms (Zone 3/Height 2/Surround Back Pre-/Line-out)
|
| Phono Overload | 70 mV (MM, 1 kHz, 0.5%) |
| Frequency Response | 10 Hz–100 kHz/ 1 dB, -3 dB (Direct Mode) |
| Tone Control | ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble) |
| Signal-to-Noise Ratio | 106 dB (IHF-A, Line) 80 dB (IHF-A, Phono) |
| Speaker Impedance | 4 Ohms–16 Ohms |
| Power Supply | AC 120 V~, 60 Hz |
| Power Consumption | 750 W |
| Standby Power Consumption | 0.1 W |
| Tuning Frequency Range | FM 87.5 MHz–107.9 MHz AM 530 kHz–1,710 kHz |
| FM/AM Preset Memory | 40 Stations |
| Dimension | 17 1/8˝ x 6 7/8˝ x 14 13/16˝ (435 x 174 x 376.5 mm) |
| Weight | 11 kg |
